Differential Active Probe Manufacturer,Supplier and Exporter in India
Product Code : EL-TILE-11527
Lab Instruments Manufacturers manufactures the Differential Active Probe in-house at our own India facility, supplying it to engineering colleges and electronics testing labs, and as an OEM/private-label item to distributors and exporters across India and internationally.
What This Probe Does
This is a wide-bandwidth (6 GHz) differential active probe used with an oscilloscope to measure differential and floating signals safely and accurately, particularly high-speed digital and RF signals where a standard passive probe would load the circuit or fail to reject common-mode noise. A switchable 2:1 or 10:1 attenuation ratio lets students and technicians match the probe's dynamic range to the signal being measured.
Key Specifications
Bandwidth: 6 GHz. Attenuation ratio: switchable 2:1 or 10:1. Dynamic range: ±1V/2Vpp at 2:1, ±5V/10Vpp at 10:1. DC offset range: ±15V. Maximum input voltage: 30V DC plus peak AC. Differential input resistance: 200kΩ. Single-ended input resistance: 100kΩ. Common-mode input resistance: 50kΩ. Input capacitance: 700fF.
Typical Lab Use
Engineering colleges and electronics testing labs use this probe alongside oscilloscopes and our Digitized Semiconductor Curve Tracer for high-speed signal measurement, differential-signal analysis, and general test-and-measurement coursework in electronics and communication engineering programs.
Manufactured In-House
This probe is designed and assembled at our own India production facility. Manufacturing in-house means our team controls build quality and calibration at every stage, and can configure the probe kit or accompanying courseware for a specific curriculum or export order without waiting on an outside supplier.
Frequently Asked Questions
What bandwidth does this probe support?
6 GHz, with a switchable 2:1 or 10:1 attenuation ratio to match the signal being measured.
What is the maximum input voltage?
30V DC plus peak AC, with a DC offset range of ±15V.
Can this be supplied as an OEM/private-label order?
Yes, it can be produced and packed under a buyer's own brand name and item codes for distributors and exporters ordering in bulk.
Related Equipment
Part of our Testing Instrument Lab Equipments range. See also Digitized Semiconductor Curve Tracer, Portable Interactive Device, and Training Bench. For pricing and specification sheets, reach us via Contact Us or the Tenders page.
