Interfacing Module Manufacturer,Supplier and Exporter in India
Product Code : EL-EELE-11326
Interfacing Module
Specifications:-
• Provision of 0 to 5V variable source using Potentiometer for One channel.
• Eight channel analog inputs are provided at Screw Terminals.
• Connect to using 26 pin FRC Connector.
• ADC module using ADC-0809.
• 8 bit accuracy ADC chip.
• Eight Channel on-chip multiplexed ADC.
• A/D Conversion time 100 micro sec.
• DAC module using DAC-0800.
• 8 bit accuracy DAC chip.
• Dual Channel DAC using 2 Nos. of DAC-0800.
• DAC Settling time 100 ns.
• DAC Output are provided at 2 Test Points.
• User’s Manual with Sample Programs.
• ADC module using AD-574 Chip.
• SOC, EOC, O/P enable can be accessed by user.
• User’s Manual with Sample Programs.
• 12 bit accuracy ADC chip.
• Signle Channel ADC module.
• A/D Conversion time 15 micro sec.
• User’s Manual with Sample Programs.
• Analog inputs are provided at Screw Terminals.
Digital Input & Output Interfacing Module
• 8 Output LED Indicators are provided.
• Connect to 8255 using 26 pin FRC Connector.
• 8 Digital Inputs provided through 8 way DIP Switch.
• 8 Input LED Indicators are provided.
• User’s Manual with Sample Programs.
Module specifications
| 8 bit ADC module | ADC-0809 |
| ADC-0809 conversion time | 100 micro sec |
| DAC module | Dual Channel DAC using 2 Nos. of DAC-0800 |
| DAC settling time | 100 ns |
| 12 bit ADC module | AD-574 |
| AD-574 conversion time | 15 micro sec |
| Digital I/O | 8 Digital Inputs provided through 8 way DIP Switch |
We are leading manufacturers, suppliers of Interfacing Module for Electronics Engineering Lab Equipments. Contact us to get high quality Interfacing Module for Electronics Engineering Lab Equipments for schools, colleges, universities, research labs, laboratories and various industries.
It pairs with the Microprocessor Trainer Kit and the Computer Interface Trainer & Modules for interfacing experiments; the Digital To Analog Converter covers conversion basics on a single board, and the Digital Signal Processor Trainer adds 16-bit conversion on a DSP platform. Find these in Electronics Engineering Lab Equipments under Electronics Lab, or contact us via Contact Us.
