Cylindrical Work Samples With Slanted Cut-Outs Manufacturer,Supplier and Exporter in India
Product Code : EL-MM-11597
Lab Instruments Manufacturers manufactures the Cylindrical Work Samples With Slanted Cut-Outs model set in-house at our own India facility, supplying it to mechatronics and mechanical engineering labs, and as an OEM/private-label item to distributors and exporters across India and internationally.
What This Model Set Does
This set contains 18 aluminium cylindrical drawing models with an anodised finish, each featuring cut-outs both parallel to and at an angle to the main axis, in finely graduated degrees of difficulty across the series. All parts are laid out on a practical, stackable tray, and the precision manufacture of the models makes them suitable for measurement exercises as well as drawing practice. The set is supported by lesson-ready instructional material.
Key details
| Models | 18 aluminium cylindrical drawing models |
| Finish | anodised finish |
| Cut-outs | both parallel to and at an angle to the main axis |
| Storage | practical, stackable tray |
| Support material | lesson-ready instructional material |
Typical Lab Use
Engineering colleges use this model set in technical-drawing and engineering-graphics coursework to teach students the progression from a solid 3D model to its more abstract 2D technical-drawing representation, complementing the machining-focused Drilling Jig For An Annular Disc model in this range.
Manufactured In-House
This model set is machined and finished at our own India production facility. Manufacturing in-house means our team controls dimensional accuracy and finish quality at every stage, and can configure the tray layout or accompanying instructional material for a specific curriculum or export order without waiting on an outside supplier.
Frequently Asked Questions
What does this model set teach?
Technical drawing and engineering graphics, using 18 precision aluminium cylindrical models with slanted cut-outs to bridge solid models and their abstract drawn representation.
Can it also be used for measurement practice?
Yes, the models are precision-manufactured specifically so they can also support measurement exercises, not only drawing practice.
Can this be supplied as an OEM/private-label order?
Yes, it can be produced and packed under a buyer's own brand name and item codes for distributors and exporters ordering in bulk.
