Concrete Cover Meter Manufacturer,Supplier and Exporter in India

Product Code : EL-CL-11885

Concrete Cover Meter

Uses:-

Suitable for non-standard bar sizes, large diameter pipes and other pre-fabricated items, this concrete cover meter measures reinforcement depth. Bar size can be preset if known, or detected automatically, for survey and investigation tasks.

It can also show absolute measurements that can be used to look up cover using custom tables.

For immediate results on-site, the onscreen gauge and audio feedback rapidly pin-point rebar location and orientation.

Accuracy:-

Cover Range	Accuracy
Up to 60 mm cover	± 1 mm
Up to 120 mm cover	± 2 mm
Up to 160 mm cover	± 3 mm
Over 160 mm cover	± 4 mm
Automatic bar sizing accuracy	± 0.5 mm to ± 1.5 mm

Specifications:-

Specification	Value
Resolution	0.1 mm
Operating Depth (6 mm bar)	Up to 60 mm cover
Operating Depth (40 mm bar)	Up to 80 mm cover
Bar Resolution - 16 mm bar	60 mm cover, 70 mm minimum spacing
Bar Resolution - 16 mm bar	100 mm cover, 110 mm minimum spacing
Bar Resolution - 25 mm bar	130 mm cover, 150 mm minimum spacing
Operating Weight	800 g
Battery Operation	20 hrs

Scope of Supply:-

Item	Details
Probe	With integral cable
Battery Charger	Included
Spare Probe Sole-Plate	Included
Certificate of Conformity	Included
Equipment Bag	Light and tough carrying bag
