Generation of Involute Gear Tooth Profile

Product Code : EL-TOMLE-11870

Generation of Involute Gear Tooth Profile
Description:-

This board illustrates the process of cutting involute gear teeth by use of a rack-type cutter.

A gear tooth profile with module 25mm can be traced out on a piece of paper placed between the disc and the cutter.

The board consists of three white acrylic discs, A, B and C, having pitch circle diameters of 450 mm, 300 mm and 200 mm respectively.

The effect of interference and undercutting on the correct profile of the gear tooth can be studied from the profiles traced out on the different discs.

Specifications:-
SpecificationValue
Cutter TypeRack-type cutter
Gear Module25 mm
Disc A - Pitch Circle Diameter450 mm
Disc B - Pitch Circle Diameter300 mm
Disc C - Pitch Circle Diameter200 mm
Disc MaterialWhite acrylic
DemonstratesInvolute gear tooth generation; interference and undercutting effects

To study the resulting profile defects in detail, see the Interference and Undercutting apparatus, and for related gear-train experiments the Epicyclic Gear Train Holding Torque Apparatus. Browse more Theory of Machine Lab Equipments, or view the full range of TVET Lab Equipments Manufacturers products.
