Interference and Undercutting

Product Code : EL-TOMLE-11871

Interference and Undercutting
Description:-

The board shows a demonstration of the phenomenon of interference and undercutting in gear teeth.

When rotation is given in the clockwise direction, the rack tip is resisted by the tooth flank, producing interference.

When the teeth are rotated in the anticlockwise direction, the teeth are undercut, giving smooth working.

Demonstration:-
ConditionObserved Effect
Rotation Direction: ClockwiseRack tip resisted by tooth flank – produces interference
Rotation Direction: AnticlockwiseTeeth undercut – gives smooth working

This phenomenon is also observed while tracing profiles on the Generation of Involute Gear Tooth Profile board, and relates to gear-train performance studied with the Epicyclic Gear Train Holding Torque Apparatus. Browse more Theory of Machine Lab Equipments, or view the full range of TVET Lab Equipments Manufacturers products.
