Grinder Tool Manufacturer,Supplier and Exporter in India

Grinder Tool

Product Code : EL-TOMLE-11878

Grinder Tool Dynamometer
Description:-

This is a simple set-up to study the various forces resolved during a grinding operation, for demonstration purposes for students undergoing tool design study.

A two-channel digital force indicator facilitates measuring both forces simultaneously.

This unit works on the octagonal ring method, using a strain gauge as a sensor.

Features:-

Rigid in construction and a compact unit.

Assessment of cutting forces giving due consideration to parameters such as depth of cut, material, speed and feed.

Easy to handle, with digital force indicators that measure two forces simultaneously.

Specifications:-
SpecificationValue
Sensing UnitMechanical sensing unit with two octagonal rings and strain gauges
Force IndicatorTwo-channel digital force indicator with balancing potentiometers and polycarbonate front plate
Force Measurement Range0 to 200 kg (coordinate direction)
Overall Size (Mechanical Unit)300 x 300 mm
Services Required:-
ServiceRequirement
Grinding MachineNecessary surface grinding machine
Electric Supply230V, single phase, 50 Hz, stabilized power supply

This is one of the Tool Dynamometers range, alongside the Lathe Tool, Milling Tool, and Drilling Tool dynamometers. Browse more Theory of Machine Lab Equipments, or view the full range of TVET Lab Equipments Manufacturers products.
