Lathe Tool Manufacturer,Supplier and Exporter in India

Lathe Tool

Product Code : EL-TOMLE-11879

Lathe Tool Dynamometer
Description:-

This is a strain-gauge type, two-component lathe tool dynamometer designed to measure vertical and horizontal forces during the orthogonal cutting process.

With this dynamometer, students can study the change in these forces by varying speed, cut and feed.

The unit consists of two parts: a mechanical sensing unit or tool holder, which can be mounted on top of the cross slide after removing the swivel base and compound slide of a lathe, and a digital force indicator.

Features:-

Rigid in construction.

Sensitive transducing and amplifying system for accuracy in force measurement.

Compact digital force indicator.

Use of cutting fluid during operation is possible.

Scope of Supply / Specifications:-
SpecificationValue
Sensing UnitMechanical sensing unit or tool holder with strain gauges
Cutting ToolH.S.S. tool of ½" size
Control PanelDigital force indicator (measures two forces simultaneously), balancing potentiometers, connecting cable
Panel FittingsNecessary switches, fuses, and polycarbonate front plate
Force Measurement Range0 to 500 kg
Mounting DimensionsCentre height, P.C.D. of clamping bolt, and clamping bolt size as per lathe
Variant AvailableThree-component lathe tool dynamometer also available

This is one of the Tool Dynamometers range, alongside the Milling Tool, Grinder Tool, and Drilling Tool dynamometers. Browse more Theory of Machine Lab Equipments, or view the full range of TVET Lab Equipments Manufacturers products.
